Zwo Asi120mc-s For Mac
Product Description Camera Sensor ASI120 camera integrates AR0130CS 1/3″ sensor (4.8 mm x 3.6 mm). This camera has 1280 x 960 pixels.
The pixel size is 3.75 μm x 3.75 μm. This camera provides 12bit ADC. Astrophotography Performance ASI120S is a super speed and sensitive USB3.0 camera.
Up to 60FPS under 1280X960 full resolution! With a peak QE of 75%, beyond ICX618 and with no FPN(Fixed pattern Noise)!
Long time exposure supported up to 1000s! Full compatible with USB 2.0 USB Host! Absolute QE Curve USB 3.0 Port & ST4 Port USB 3.0 Port: can provide 5Gb bandwidth to let ASI120S run at 60 fps (10bit, high speed mode) at full resolution(1.2Mega). ST4 Port: can be used connect with auto guide port of mount, for guiding. Mechanical Diagram What is in the box? Shipping. Fast Shipping(amount ≧ 299USD) for free.
Fast Shipping(amount.
DESCRIPTION ZWO ASI 120 Super Speed Color CMOS Telescope Camera The ASI120S Super Speed Sensitive Color CMOS Camera - USB 3.0 by ZWO: A versatile camera has just become faster! Featuring a USB 3.0 connection, image download times are lightning fast. The ZWO ASI120 Super Speed Sensitive Color camera is a perfect choice for lunar and planetary imaging and features a CMOS sensor sensitive enough to capture bright deep-sky objects.
Truly a 'do it all' camera at an incredible price making it the clear choice for the serious beginning or intermediate astrophotographer. The ASI120MC-S is built o n a 1/3 inch CMOS AR0130S full color sensor. Capable of producing single shot images in full color without the need for color filters. The pixel array of 1280x960 and a pixel size of 3.75 micron square, this camera is capable of capturing moderately wide fields with the included 150-degree wide angle lens adapter. Peak QE is 75-percent with absolutely no fixed pattern noise.
Protecting the sensor is an IR-cut window. An ultra fast incarnation of its predecessor, the ZWO ASI120S has the ability to deliver frames at 254 per second with reduced resolution or 60 frames per second at full resolution. This wide range of resolution and capture settings allows you to switch from planetary and lunar imaging to DSO's easily without having to weigh down your set up with an additional camera. Housed in a gorgeous metallic red aluminum housing with both a USB 3.0 and ST4 autoguider port 6.5-foot cables for both are included as are a 2-inch M42x0.75 threaded interface and standard M42 to 1.25-inch nosepiece. A 1/4-20 thread in the center bottom of the camera makes for easy attachment to a wide variety of camera mounts and tripods. 4 M4 threads offer additional mounting positions, along the outside edge.
This camera will include:. 2 m long USB 3.0 cable.
Zwo Asi120mc-s For Mac Download
2 m long ST4 guider cable. 1.25-inch IR-cut window.
150-degree wide-angle lens-adapter. Driver and Software -On-line link is in the 'INCLUDED ITEMS' Tab above. M42 to 1.25-inch nosepiece The Software on the CD includes:.
A user manual. Windows camera driver. ASCOM driver. SharpCap image capture software. FireCapture image capture software. Stakkert 2 stacking software for post processing - SPECIFICATIONS.
